Toledo Tools TT7 7.5 HP Tankless Rotary Screw Air Compressor

(No reviews yet) Write a Review
SKU:
FTT07
MSRP: $10,336.00
$7,855.36
— You save $2,480.64
Frequently bought together:

Description

The Toledo Tools TT7 compressor is a 7.5 HP air-cooled, single-stage, base-mounted (tankless), engineered by FS-Curtis for demanding industrial duty. Rated for 23.7 CFM at 150 PSI, it delivers stable, continuous-duty shop air and is a rugged, industrial-grade step up from reciprocating and consumer-grade compressors, with quieter operation and far longer service life.

Backed by more than 170 years of FS-Curtis engineering and a nationwide network of factory-trained service technicians, the TT7 is built for shift-after-shift reliability at an approachable price. It is a proven workhorse for manufacturing and assembly lines, automotive, woodworking, printing, packaging, textiles, and asphalt or concrete operations.

Free Air Delivery (CFM) by Working Pressure

Working Pressure125 PSI150 PSI175 PSI
Free Air Delivery (CFM)26.623.719.2

Key Features

Rugged, long-life construction: a large-rotor airend turning at low RPM reduces wear and heat for dependable, long-term operation.

100% continuous duty: rated for around-the-clock industrial use with no duty-cycle limit.

iCommand controller: intuitive load / no-load control between two pressure settings, with built-in protection and diagnostics.

Premium-efficiency motor: NEMA premium TEFC (IP55, Class F) motor built for heavy industrial loads.

Integrated oil separation and filtration: a high-efficiency separator delivers clean air with low residual carryover; a heavy-duty suction filter, oil sight glass, and accessible drain simplify service.

Quiet operation: a sound-attenuated package with centrifugal cooling keeps the noise footprint low on the plant floor.

Warranty: a 1-year warranty from day one, extendable up to 5 years on the airend through the Toledo Tools Extended Warranty when registered online and maintained with genuine FS-Curtis parts and fluids.

Documents & Downloads

Data Sheet

FAQ

How much air does the TT7 deliver?

The TT7 produces 23.7 CFM at 150 PSI (and 26.6 / 23.7 / 19.2 CFM at 125 / 150 / 175 PSI) from its 7.5 HP airend.

Does the TT7 include an air tank?

No. The TT7 is a base-mounted (tankless) unit that feeds an existing receiver or plant air system. If you need a tank, choose the TT7T (tank-mounted) or the TT7UP UltraPack, which adds a refrigerated dryer and filters.

What voltage and phase does it require?

Choose 208-230V single-phase or three-phase at checkout.

Is the TT7 rated for continuous use?

Yes. Like all Toledo Tools rotary screw compressors, it is built for 100% continuous duty and can run around the clock without a duty-cycle limit.

What warranty is included?

A 1-year warranty from day one, extendable up to 5 years on the airend through the Toledo Tools Extended Warranty when registered online and maintained with genuine FS-Curtis parts and fluids.

View AllClose

Additional Information

Type:
Tankless Rotary Screw Compressor
Horsepower:
7.5 HP
Drive:
Fixed Speed
Voltage:
208-230V (1 or 3 Phase)
Phase:
1 or 3 Phase
Flow Rate:
23.7 CFM
Rated Pressure:
150 PSI
Maximum Operating Pressure:
175 PSIG
Decibels:
65 dBA
Controller:
iCommand
After Cooler:
Yes
Air Dryer:
No
Tank:
No
Tank Volume:
None
Filters:
Yes
Magnetic Starter:
Yes
Oil Sight:
Yes
Weight:
529 lbs
Width:
24 in
Length:
26 in
Height:
35 in
Warranty:
5-Yr Airend / 2-Yr Major
View AllClose
