Toledo Tools TT5T 5 HP Tank Mounted Rotary Screw Air Compressor

(No reviews yet) Write a Review
SKU:
FTT05T
MSRP: $9,719.00
$7,386.44
— You save $2,332.56
Frequently bought together:

Description

The Toledo Tools TT5T compressor is a 5 HP air-cooled, single-stage rotary screw compressor mounted on a 53-gallon ASME air receiver tank, engineered by FS-Curtis for demanding industrial duty. Rated for 16.6 CFM at 150 PSI, it delivers stable, continuous-duty shop air and is a rugged, industrial-grade step up from reciprocating and consumer-grade compressors, with quieter operation and far longer service life.

Backed by more than 170 years of FS-Curtis engineering and a nationwide network of factory-trained service technicians, the TT5T is built for shift-after-shift reliability at an approachable price. It is a proven workhorse for manufacturing and assembly lines, automotive, woodworking, printing, packaging, textiles, and asphalt or concrete operations.

Free Air Delivery (CFM) by Working Pressure

Working Pressure125 PSI150 PSI175 PSI
Free Air Delivery (CFM)17.116.612.4

Key Features

Rugged, long-life construction: a large-rotor airend turning at low RPM reduces wear and heat for dependable, long-term operation.

100% continuous duty: rated for around-the-clock industrial use with no duty-cycle limit.

iCommand controller: intuitive load / no-load control between two pressure settings, with built-in protection and diagnostics.

Premium-efficiency motor: NEMA premium TEFC (IP55, Class F) motor built for heavy industrial loads.

Integrated oil separation and filtration: a high-efficiency separator delivers clean air with low residual carryover; a heavy-duty suction filter, oil sight glass, and accessible drain simplify service.

Quiet operation: a sound-attenuated package with centrifugal cooling keeps the noise footprint low on the plant floor.

Integrated 53-gallon receiver: the ASME-rated tank stabilizes pressure and provides ready air storage, mounted and piped as one package.

Warranty: a 1-year warranty from day one, extendable up to 5 years on the airend through the Toledo Tools Extended Warranty when registered online and maintained with genuine FS-Curtis parts and fluids.

Documents & Downloads

Data Sheet

FAQ

How much air does the TT5T deliver?

The TT5T produces 16.6 CFM at 150 PSI (and 17.1 / 16.6 / 12.4 CFM at 125 / 150 / 175 PSI) from its 5 HP airend.

What size tank does the TT5T include?

It is mounted on a 53-gallon ASME air receiver tank, piped as one package for stable pressure and ready air storage.

What voltage and phase does it require?

Choose 208-230V single-phase or three-phase at checkout.

Is the TT5T rated for continuous use?

Yes. Like all Toledo Tools rotary screw compressors, it is built for 100% continuous duty and can run around the clock without a duty-cycle limit.

What warranty is included?

A 1-year warranty from day one, extendable up to 5 years on the airend through the Toledo Tools Extended Warranty when registered online and maintained with genuine FS-Curtis parts and fluids.

View AllClose

Additional Information

Type:
Tank Mounted Rotary Screw Compressor
Horsepower:
5 HP
Drive:
Fixed Speed
Voltage:
208-230V (1 or 3 Phase)
Phase:
1 or 3 Phase
Flow Rate:
16.6 CFM
Rated Pressure:
150 PSI
Maximum Operating Pressure:
175 PSIG
Decibels:
65 dBA
Controller:
iCommand
After Cooler:
Yes
Air Dryer:
No
Tank:
Yes
Tank Volume:
53 Gallon
Filters:
Yes
Magnetic Starter:
Yes
Oil Sight:
Yes
Weight:
959 lbs
Width:
24 in
Length:
54 in
Height:
57 in
Warranty:
5-Yr Airend / 2-Yr Major
View AllClose
