Walker E30731X5 Compressed Air Filter Element – 5 Micron Coalescing (Grade X5)

The Walker E30731X5 is a genuine Walker Filtration 5 Micron Coalescing replacement coalescing filter element for Alpha series compressed air and gas filter housings. Deep-pleated media delivers 99.999% efficiency tested in accordance with ISO 12500-3, with a low differential pressure that keeps running cost down over the life of the element.

5 Micron Coalescing — Grade X5

Rated for 5 micron removal. Push-fit element design makes servicing quick and clean.

Fits These Housings

This element is the genuine Walker Filtration replacement for:

• Walker A30280 Alpha 1 1/4" NPT Compressed Air Filter - 280 SCFM
• Walker A30320 Alpha 1 1/2" NPT Compressed Air Filter - 320 SCFM

Replacement & Maintenance

Replace every 12 months, or sooner if the differential pressure indicator signals, to maintain rated air quality and minimize energy cost. Genuine Walker Filtration element — part number E30731X5.

Which Housings Take This Element?

The E30731X5 is the 5 micron coalescing element for these Walker housings. The housing is the same across grades — only the element changes:

• A30280 — 1-1/4" — 280 SCFM
• A30320 — 1-1/2" — 320 SCFM

Replace on the differential pressure indicator or every 12 months, whichever comes first.

View the Walker Alpha Compressed Air Filter Datasheet
